Automatic
Euro 5
4752ml
12880kg
Diesel
4x2
200-300hp
New
Nude
9180*2490*3100mm
JSIE
China
8705909990
3000units/Year
| Chasis: | STEYR MOTORS. | |
| Emission Standard: | Euro 5 | |
| Engine Type: | MAN SE. | |
| Engine Power: | 310hp. | |
| Wheel Base: | 5200mm. | |
| Maximum Speed: | 90km/h. | |
| Tyre Size: | 12.00R20 18PR. | |
| Maximum Height of Frame: | 37m. | |
| Frame Horizontal Fabric Radius: | 33.4m. | |
| Fabric Depth: | 26.5m. | |
| Arms Rotation Angle: | 90/180/180/235/235. | |
| Frame Control Mode: | Proportional Control of Load-sensitive. | |
| Frame Quantity: | 5 | |
| Folding Pattern: | RZ type. | |
| Brick Tower Rotation Angle: | 370°. | |
| Longitudinal Distance Between Front and Rear Support Legs: | 6947mm. | |
| Support Leg Opening Mode: | X-R. | |
| Conveying Diameter: | 125mm. | |
| Electric Control: | 24V. | |
| Wireless Remote Control Brand: | HBC or OHM. | |
| Hydraulic System Type: | Opening. | |
| Working Pressure of the Hydraulic System: | 31.5Mpa. | |
| Main Hydraulic Pump Brand: | Rexroth or Push. | |
| Frame Multiway Valve Brand: | HAWE or RADK-TECH. | |
| Capacity of Hydraulic Tank: | 500L. | |
| Hydraulic Cleaning Device: | Himore. | |
| Concrete Piston Brand: | Made in China. | |
| Maximum Height of Loading: | 1450mm. | |
| Hopper Volume: | 0.65m³. | |
| Pumpable Concrete Slump: | 160-220. | |
| Allowable Maximum Aggregate Size: | 40mm. | |
| Lubrication Method: | Centralized Lubrication. | |
| Chasis: | STEYR MOTORS. | |
| Emission Standard: | Euro 5 | |
| Engine Type: | MAN SE. | |
| Engine Power: | 310hp. | |
| Wheel Base: | 5200mm. | |
| Maximum Speed: | 90km/h. | |
| Tyre Size: | 12.00R20 18PR. | |
| Maximum Height of Frame: | 37m. | |
| Frame Horizontal Fabric Radius: | 33.4m. | |
| Fabric Depth: | 26.5m. | |
| Arms Rotation Angle: | 90/180/180/235/235. | |
| Frame Control Mode: | Proportional Control of Load-sensitive. | |
| Frame Quantity: | 5 | |
| Folding Pattern: | RZ type. | |
| Brick Tower Rotation Angle: | 370°. | |
| Longitudinal Distance Between Front and Rear Support Legs: | 6947mm. | |
| Support Leg Opening Mode: | X-R. | |
| Conveying Diameter: | 125mm. | |
| Electric Control: | 24V. | |
| Wireless Remote Control Brand: | HBC or OHM. | |
| Hydraulic System Type: | Opening. | |
| Working Pressure of the Hydraulic System: | 31.5Mpa. | |
| Main Hydraulic Pump Brand: | Rexroth or Push. | |
| Frame Multiway Valve Brand: | HAWE or RADK-TECH. | |
| Capacity of Hydraulic Tank: | 500L. | |
| Hydraulic Cleaning Device: | Himore. | |
| Concrete Piston Brand: | Made in China. | |
| Maximum Height of Loading: | 1450mm. | |
| Hopper Volume: | 0.65m³. | |
| Pumpable Concrete Slump: | 160-220. | |
| Allowable Maximum Aggregate Size: | 40mm. | |
| Lubrication Method: | Centralized Lubrication. | |
