Automatic
Diesel
12490kg
Euro 2
6×4
9L
2 Seats
351-450hp
ECE, GCC, ISO, DOT
Radial
Front Lifting Style
New
Nude
8545x2496x3170mm
JSIE
China
8704109000
5000units/Year
SPECIFICATION | |||
MODEL | JSIEZZ3259N384PB3 | ||
Size | size of the truck | LXWXH | 8545x2496x3170mm |
size of the box | LXWXH | 5800x2300x1300mm | |
wheelbase | 3825+1350mm | ||
overhang | 1500/1870mm | ||
min Ground Clearance) | 314mm | ||
Weight | Minimum turning diameter | 17m | |
Angle of approch/Departure | 29/23° | ||
Performance | Dead weight | kg | 12380 |
rated weight | kg | 12490 | |
Max.speed | km/h | 78 | |
Engine | Rated Power | KW/r/min | 276 |
Max. torque | N.m/R/min | 1500/1100-1600 | |
The ignition sequence | 1-5-3-6-2-4 | ||
Clutch | Size | mm | φ430 |
Gear box | speeds | 10 | |
Ratio | 12.28,10.62,7.87,5.88,4.38,3.27,2.43,1.8,1.34,1.00 | ||
R 13.91,3.18 | |||
Axle | Driving axle | AC16 | |
Ratio | 5.45 | ||
Front axle | HF9 | ||
Suspension | Suspension | NS07 with leaf springs | |
Brake | Parking brake | spring brake | |
Service brake | Daul circult air brake | ||
Auxiliary braking | EVB | ||
Fuel | Fuel tank | 400L |
