| Quantity: | |
|---|---|
Automatic
Euro 5
3767ml
10-15ton
Diesel
4x2
160HP
New
Perfect for The Long Term Usage
Nude
7585x2500x3720mm
JSIE
China
8705400000
3000units/Year
| Basic Specification Parameter | |
| Model | JSIEQ5180G |
| 1,Basic Parameter | |
| Overall Length/Width/Height (mm): | 7585x2500x3720 |
| Curb Weight (kg): | 7600 |
| Chassis Brand and Model: | Dongfeng EQ1180G |
| Wheelbase(mm): | 3800 |
| Front / Rear overhang (mm): | 1500 / 2150 |
| Approach / Departure Angle: | 20-/13- |
| Front / Rear wheel distance (mm): | 1940 /1860 |
| 2, Chassis Specification | |
| Engine: | YC4S160-50 |
| Engine Type | Line cylinder, Water cooling, Turbo |
| Max HP and Power (km/rpm) | 160HP, 118KW |
| Engine Displacement: | 3767ml |
| Fuel Type: | Diesel |
| Emission Level: | Euro 5 |
| Gearbox Model: | Fast 8JS85T |
| Gear Specification: | 8 advance gear, 1 reverse gear |
| Carframe Specification: | 250/7+4 |
| Carframe Section Height: | 250mm |
| Section Width: | 80mm |
| Section Thickness: | 7+4 |
| Front Axle Description: | Forge steel beam axle, H shape beam section |
| Front axle load(kg): | 5000 |
| Rear Axle Description: | Single reduction axle, welding axlecase |
| Rear axle load(kg): | 10000 |
| Rear axle speedratio: | 5.26 |
| Suspension Spring Type: | Multi leaves steel plate spring |
| Suspension Spring Specification: | Front 9 leaves, Rear 13 leaves |
| Brake system: | Service brake: Duo loop air brake, steel tube with dryer |
| Parking brake: Cut-off air brake | |
| Steering system: | Hydraulic power steering |
| Fuel Tank Cubage: | 300L |
| Tyre Qty: | 6 wheels |
| Tyre Specification: | 10.00R20 14PR |
| 3, Modification Describtion | |
| Geometric volume of mixer drum: | 6 CBM |
| Max mixing cubage: | 4 CBM |
| Feeding speed: | >=3 CBM |
| Discharging speed: | >=3 CBM |
| Leftover Rate: | ≤0.3% |
| Max ratating speed of mixer drum: | 14-16 (r/min) |
| Mixer drum obliquity: | 5-10 Degree |
| Mixer drum diameter: | 2050mm |
| Speed reducer: | PMP/WPM/ZF/BONFIGLIOLI |
| Hydraulic pump: | SAO/interpump |
| Hydraulic motor: | SAO/interpump |
| Water supply mode: | Water pump |
