Automatic
Diesel
12.7ton
Euro 4
6×4
9L
ZZ3257N3247D
2 Seats
380HP
ECE, GCC, ISO, DOT
Radial
Front Lifting Style
New
Left Hand Driving
Nude
8150*2550*3400mm
SINOTRUK
China
8704223000
5000units/Year
Kerb weight (vehicle/chassis) kg | 12700 |
Gross Mass kg | 25000 |
Rated load kg | 12680 |
Complete vehicle overall dimensions(L×W×H) mm | 8150*2550*3400 |
Engine | D10.38-40,380HP, EURO4 emission |
Transimission | HW19710,10 forward speed |
Cargo box dimensions(L×W×H) mm | 5600×2300×1600 |
Volume | 18m³ |
Steering | ZF brand |
Tires | 12R22.5 with one spare tire |
Wheelbase mm | 3600+1350 |
Front/rear overhang (vehicle/chassis) mm | 1500/(1470/715) |
Minimum ground clearance mm | 314 |
Appraoach/departure angle(vehicle/chassis) ° | 19/24,19/30 |
Maximum speed km/h | 75 |
Max hillholding ability % | 20 |
MInimum turning diameter m | 15 |
Fuel tank | 300L |
Accessory | Air-conditioner and safety belts |
Date of manufacture | 2020 |
